Specification
Model No.	NAC-1884 TOP	NAC-1884 SUBA
Components	8x4"woofer	18"subwoofer
Frequency Response (Hz)	120-18K	40-150
RMS Power (W)	300	1000
Program Power (W)	600	2000
Max SPL (dB)	127	132
Flying points	/	/
Connection	SPEAKON	COMBO/SPEAKON
Product Weight (kg)	9.1	34.5
Gross Weight (kg)	10	36.5
Product Size (cm)	13.5x17x105	60x58x53.5
Shipping Carton Size (cm)	112.5x36x25	67.5x65.5x61.5
Amplifier Module
Output Power(EIA test standard,100Hz 1%THD)	2x1000W/4 Ohms
S/N	95dB
Damping Factor	500@100Hz
Protection	over voltage protection up to 264V AC,overload output protection,clip,limiter
Drawing
